KnowFlow

July 2025 - August 2025

KnowFlow is a powerful hybrid Retrieval-Augmented Generation (RAG) system that combines semantic search with knowledge graph capabilities for intelligent document processing and querying.

Python
AWS
TypeScript
Neo4j
PostgreSQL
pgvector
Google Gemini
S3
JWT
bcrypt
RAG
Knowledge Graph
Vector Search
KnowFlow
Problems Solved
  • Traditional RAG systems fail at complex multi-hop reasoning questions
  • Semantic search alone misses structured entity relationships
  • Document processing lacks context preservation across sessions
Unique Solution

Combines dense vector embeddings with Neo4j knowledge graphs for hybrid retrieval, enabling both semantic similarity and multi-hop reasoning. Implements intelligent query decomposition to extract entities and relationships automatically while maintaining conversation context.

Impact
3x
Query Types Supported
Session-based
Context Preservation
Multi-format
Document Processing

Deployment (HLD)

diagram-export-7-20-2025-6_03_33-PM

AI Infra

diagram-export-7-20-2025-6_57_03-PM

KnowFlow is a powerful hybrid Retrieval-Augmented Generation (RAG) system that combines semantic search with knowledge graph capabilities for intelligent document processing and querying.

Features

  • Advanced Document Processing

    • Multi-format support (PDF, DOCX, CSV, TXT)
    • Intelligent chunking with configurable size and overlap
    • Parallel batch processing with S3 storage
    • Document status tracking (PENDING, PROCESSING, INDEXED, FAILED)
    • Secure per-user document isolation

  • Hybrid RAG + Knowledge Graph Architecture

    • Dense semantic embeddings via Google Gemini + pgvector
    • Structured knowledge extraction to Neo4j
    • Multi-hop reasoning through graph relationships
    • Automatic entity and relationship mapping
    • Query decomposition for complex questions

  • Smart Query Processing

    • Automatic query decomposition for complex questions
    • Hybrid vector + graph-based retrieval
    • Retrieval quality evaluation and improvement
    • Context-aware response synthesis
    • Conversation memory with graph context

  • Chat & Session Management

    • Persistent chat sessions with history
    • Context-aware follow-up questions
    • Session renaming and management
    • Message tracking with context preservation
    • Multi-user support with isolation

  • Security & Authentication

    • JWT-based authentication
    • Secure password hashing with bcrypt
    • Role-based access control
    • Per-user data isolation
    • Document access verification

  • Storage & Infrastructure

    • S3-compatible object storage
    • PostgreSQL for structured data
    • Neo4j for graph relationships
    • Concurrent file operations
    • Efficient batch processing

Quick Start

Prerequisites

  • Python 3.8+
  • PostgreSQL 14+ with pgvector extension
  • Neo4j 5.0+
  • S3-compatible storage
  • Google Cloud API key for Gemini

Environment Variables

# Database
DATABASE_URL=postgresql://user:pass@localhost:5432/knowflow
VECTOR_COLLECTION_NAME=document_embeddings

# Neo4j
NEO4J_URI=bolt://localhost:7687
NEO4J_USER=neo4j
NEO4J_PASSWORD=password

# Google API
GOOGLE_API_KEY=your_gemini_api_key
GEMINI_MODEL_NAME=gemini-pro
GEMINI_EMBEDDING_MODEL=embedding-001

# AWS S3
AWS_ACCESS_KEY_ID=your_access_key
AWS_SECRET_ACCESS_KEY=your_secret_key
AWS_REGION=us-east-1
S3_BUCKET_NAME=knowflow-documents

# App Settings
SECRET_KEY=your_jwt_secret_key
ACCESS_TOKEN_EXPIRE_MINUTES=60
CHUNK_SIZE=1000
CHUNK_OVERLAP=100
TOP_K_RESULTS=3

Development Setup

  1. Clone the repository:
git clone https://github.com/yourusername/knowflow.git
cd knowflow
  1. Install dependencies:
pip install -r requirements.txt
  1. Run migrations:
alembic upgrade head
  1. Start the development server:
uvicorn src.main:app --reload

API Documentation

Authentication

  • POST /auth/register - Register new user
  • POST /auth/login - Login and get JWT token
  • GET /auth/me - Get current user info

Documents

  • POST /documents/upload - Upload multiple documents
  • POST /documents/{doc_id}/index - Index document content
  • GET /documents - List user documents
  • GET /documents/{doc_id} - Get document details

Chat

  • POST /chat/query - Process a new query
  • POST /chat/sessions/{session_id}/messages - Send follow-up message
  • GET /chat/sessions - List chat sessions
  • PUT /chat/sessions/{session_id}/rename - Rename session
  • DELETE /chat/sessions/{session_id} - Delete session

Security Features

  • JWT-based authentication with expiration
  • Bcrypt password hashing
  • Per-user document isolation
  • Access control verification
  • Secure file storage paths
  • Input validation and sanitization

Monitoring & Logging

  • Structured logging with levels
  • Request/response tracking
  • Error handling and reporting
  • Performance metrics
  • Document processing status
  • Chat session analytics

License

This project is licensed under the terms of the LICENSE file included in the repository.
